Relay It|12v 30a Time Delay Relay Spdt 5s/10s Sealed For Auto Control

- Rated Voltage: 12V - Operating Voltage: 11VDC ~ 15VDC - Delay time (operate time): 10SS ± 1S - Contact Rating (resistive): 30A/14VDC - Max. Switching power: 420W - Weight (approx. ): 40g Pin lay-out; 30: Positive 12V feed power (from battery for example) 85: Negative / Ground 86: Positive 12V trigger to activate relay and timer (from headlight switch for example) 87: 10 second delayed output positive (Normally open) (to HID ballast for example) 87a: Normally closed and unused (12V positive when 12V on pin 86, power switched to pin 87 after 10S). This relay fits most common single or dual beam HID wiring harnesses for an easy fix to prevent HID from starting before cranking the engine. 10 second delay before switching On Avoid those pesky ignition errors, flickering/fluttering HID, and needless wear and tear on ballasts.
